OIS . ENCODER . VCM
STABLE PRODUCTION YIELD OF VARIOUS CAMERA MODULE 5M FF ~ 108M AF, OPTICAL ZOOM IN/OUT
- OIS. OPTICAL IMAGE STABILIZATION
- refers to the technology that prevents or compensates for shaking in the image due to movement of the device arising
from unstable fixture or grip. Normally, when taking photos right before sunrise, right after sunset, or in dark indoor spaces without
supplementary lighting, the resulting images tend to appear wobbly. This happens because of the slower shutter speed (auto exposure)
together with shaking of the photographer's hands owing to an unstable posture. Thus,
image stabilization technology was developed to minimize instances of such cases.
- ENCODER
- Technology using bearing, coil, and axle
- VCM
- Technology using voice coil
Development and production of actuator for smartphone useTotal of 12.5 million Capacity
“Proceeding with production using in-house actuator (internalization)
in driving systems of 12 M ~ 108 M cameras”
Vietnam ACTUATOR capacity/month : ENCODER 2M, OIS : 10.5M
| PRODUCT | TYPE | RESOLUTION | DIMENSION |
|---|---|---|---|
 |
CVCA (BALL) | 40M | 9.1 x 9.74 / 3.76T |
 |
OIS (BALL) | 64M | 13.7 x 13.1 / 4.65T |
 |
OIS (BALL) | 12M | 13.7 x 13.1 / 4.65T |
 |
OIS (BALL) | 10M | 11.1 x 11.1 / 5.65T |
 |
OIS (BALL) | 64M | 13.5 x 13.5 / 4.8T |
 |
OIS (BALL) | 8M | 10.0 x 10.0 / 4.3T |
 |
OIS (BALL) | 48M | 12.5 x 12.1 / 4.3T |
 |
OIS (BALL) | 12M | 11.3 x 11.7 / 3.95T |
 |
OIS (BALL) | 64M | 13.5 x 13.5 / 4.8T |
 |
OIS (BALL) | 50M | 14.8 x 15.3 / 4.1T |
 |
OIS (BALL) | 12M 3X | 11.1 x 11.1 / 5.15T |
 |
OIS (BALL) | 108M | 13.9 x 13.9 / 4.8T |
 |
ZOOM (BALL) | 12M | 36.2 x 14 / 6.2T |
 |
OIS (BALL) | 200M | 18.0 x 18.7 / 4.9T |
GIMBAL . Tilt OIS
- Exterior Drawing and Characteristics
-
- Using MODULE TILT form, no more resolution deterioration
problem as in pre-existing LENS SHIFT/TILT form - Compared to pre-existing commercialized methods, correction angle doubled
(1.5 deg → ± 3 deg) - Existing commercialized product : Supports hand shaking correction
- Module Tilt OIS : Supports hand shaking correction + external shaking
(shooting while moving on uneven topography, etc.) correction
- Using MODULE TILT form, no more resolution deterioration
- RC MODEL CAR
- TILT. OIS OFF
- TILT. OIS ON
TILT OIS. VIDEO
